AGM stands for Absorbed Glass Mat where the electrolyte in the cell is locked in a fiberglas mat between the plates. This valve regulated lead acid technology is low maintenance because it never needs watering.
|
||||
Innovotive Features
Component
Specification Document
Innovotive Features
PPCP Containers with Low permeability to ensure that there is no water loss
. Side wall design to maintain structural integrity in high operating temperatures.
High Compression Absorbent Glass Mat (AGM) Separator for greater than 98% recombination efficiency.
Heavy duty L terminal best suited to carry high rate discharges.
Highly reliable one way self resealing safety vent seal
. MFX alloy grid for high design life in float @ 27° C with maximum cyclic life.
FLAPPON Terminal protecting system to prevent short circuits
. Ergonomic design for easy handling
. Grouping the plates by Cast-On-Strap leads to integral lead crystals provides superior corrosion resistance to negative strap
. Superior high rate discharge with low internal resistance.
Component
. Superior high rate discharge performance upto 8% more than rectilinear profile.
. Low self discharge less than 1% per week.
. Superior compression characteristics
Thick, robust inter-cell connections
. Imparts high reliability during service life
. Minimizes low resistance path.
Specification Document
| Dimension (±2mm) | ||||||
| Model | Voltage (Volts) |
Capacity Ah @ 20 hr |
Length | Width | Height | Weight (Kgs)(±5%) |
| 12AL007 | 12 | 7.2 | 151 | 66 | 95 | 2.2 |
| 12AL018 | 12 | 18 | 181 | 78 | 166 | 6.5 |
| 12AL026 | 12 | 26 | 167 | 126 | 175 | 9.0 |
| 12AL042 | 12 | 42 | 199 | 167 | 175 | 14.0 |
| 12AL065 | 12 | 65 | 351 | 167 | 175 | 20.0 |
| 12AL084 | 12 | 84 | 351 | 167 | 203 | 27.0 |
| 12AL100 | 12 | 100 | 441 | 167 | 216 | 35.0 |
| 12AL130 | 12 | 130 | 447 | 168 | 247 | 42.0 |
| 12AL160 | 12 | 160 | 447 | 168 | 283 | 52.0 |
| 12AL200 | 12 | 200 | 556 | 186 | 263 | 62.0 |
